510AJ Specs
Platform Height: 15.81m
Horizontal Outreach: 9.48m
Up and Over Height: 7.67m
Swing (non continuous): 360°
Platform Capacity – Unrestricted: 230kg
Platform Rotator (Hydraulic): 180°
Jib – Overall Length: 1.24m
Jib – Range of articulation: 145° (+78°/ -67°)
A. Platform Size: 0.76m x 1.83m
B. Overall Width: 2.34m
C. Tailswing (working condition): Zero
D. Stowed Height: 2.29m
E. Stowed Length: 7.68m
F. Wheelbase: 2.34m
G. Ground Clearance 0.29m
Machine weight: 7,650kg
